Item: YB-LG-60MA - LG-60MA LED Power Driver ( LED Power Supply )

Item: YB-LG-60MA
Product Name: LG-60MA LED Power Driver ( LED Power Supply )

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
  • With 1-10v dimming function
  • Build-in 3-in-1, intelligent time isolated dimming function ( dim off or not )
  • With auxilliary power  +12V ( optional )LG-35MALG-40MALG-50MA
picture (image) of lg-60ma.jpg

Description

Power: 60W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features

Efficiency up to 89%
Isolated Dimming(Optional): 0-10V, PWM, Resistor
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LG-60M023A (100-277)Vac (11-23)Vdc (2.6-5.45)A 60W
LG-60M033A (100-277)Vac (20-33)Vdc (1.8-3)A 60W
LG-60M054A (100-277)Vac (33-54)Vdc (1.1-1.81)A 60W
