Item: YB-LD-150MH - LD-150MH LED Power Driver ( LED Power Supply )

Item: YB-LD-150MH
Product Name: LD-150MH LED Power Driver ( LED Power Supply )

  • Constant current mode
  • Isolated power supply with aluminium case
  • Double stage circuit, flicker free
  • Output current adjustable
  • Build-in 3-in-1, intelligent time isolated dimming function ( dim off or not )
  • With auxilliary power  +12V ( optional )
picture (image) of ld-150mh.jpg

Description

Power: 150W
Application: Street light, Highbay, Flood light, Stage light and High-pole light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features

Efficiency up to 92%
Isolated Dimming(Optional): 1-10V, PWM, Resistor and Timming
IP67
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 6kV, L/N-PE: 10kV



Model AC Input Range DC Output Range Output Current Output Power
LD-150M042H (100-277)Vac (24-42)Vdc 2.8-4.7A 150W
LD-150M058H (100-277)Vac (32-58)Vdc 2.0-3.6A 150W
LD-150M108H (100-277)Vac (54-108)Vdc 1.0-2.1A 150W
LD-100M215H (100-277)Vac (108-215)Vdc 0.5-1.05A 150W
