Item: YB-LI-30M - LI-30M LED Power Supply ( LED Power Driver )

Item: YB-LI-30M
Product Name: LI-30M LED Power Supply ( LED Power Driver )

  • Constant current mode
  • Isolated power supply with iron case
  • Isolated with double stage circuit, flicker free
  • Build-in 3-in-1, intelligent time isolated dimming function, dim off or not
  • Isolated auxiliary power ( +12V, +24V )
  • Build in protection function of short circuit, over current, over voltage and over temperature
picture (image) of li-30m.jpg

Description

Power: 30W
Application: Street light,Highbay,Flood light,Stage light and High-pole light
Certificates: UL ClassP,TUV,CCC,CE
5 Years Warranty

Features

Efficiency up to 86%
Isolated Dimming(Optional): 0-10V,PWM,Resistor and Timming
IP65
Protections: SCP/OTP/OVP/OPP
Surge Protection: L-N: 2kV,L/N-PE: 4kV
Operation temperature: -30~+55



Model AC Input Range DC Output Range Output Current Output Power
LI-30M042 (100-277)Vac (25-42)Vdc 0.5-0.85A 30W
LI-30M055 (100-277)Vac (42-55)Vdc 0.3-0.65A 30W
LI-30M090 (100-277)Vac (55-90)Vdc 0.2-0.4A 30W






FAQs:

1. How long does it take to get the quotation?
For any interest of our products, you are very welcome to send us feedback or contact us. We will reply ASAP! Generally it takes within 12 hours. For any quick response, please call us directly.

2. How can I get a sample?
Samples are free, however, we charge the shipping cost, which could be deducted in the later order as long as the amount reach our MOQ.

3. Can you provide OEM or ODM service?
Surely we can. We have a professional team which has rich experience in lighting field. A lot of our products carrying our ideas are well sold in North America and European market.

4. What's the lead time for mass production?
It depends on the amount. Generally it takes a month after deposit payment for us to finish the order.

5. What is the terms of delivery?
Generally we offer FOB, however, EXW,CIF,etc are also welcome. Feel free to choose the one suit you best.
